OSHA LVL Pine Scaffold Board
LVL (Laminated Veneer Lumber) is a new construction material.It can be customised to create high value products for residential, commercial,formwork and scaffolding applications. Construction Grade LVL (laminated veneer lumber)
OSHA LVL Pine Scaffold Board
LVL (Laminated Veneer Lumber) is a new construction material.It can be customised to create high value products for residential, commercial,formwork and scaffolding applications. Construction Grade LVL (laminated veneer lumber)
| Product Name | OSHA LVL Pine Scaffold Board |
| Raw Material | New Zealand Radiate Pine LVL ,Poplar LVL |
| Thickness | 20,38,39,42,55 up to 220 mm. |
| Width | 100,130,150,220,225,230, up to 1300 mm. |
| Length | 1000, 1900,2450, 2750, 2.900, 3000, 4000,4500, 4900, 5300,5900 mm, up to 6000 mm |
| Glue | WBP Melamine, Phenolic F4 |
| Standard | OSHA,ANSI A10.8(US), BS24829(UK), AS1577(AUS) |
| Moisture Content | <15% |
| Density | 550-600 kg/m2 |
| End finish | waterproof paint, yellow, blue, green and for your request. |
| Surface finish | polishing, non-slip, construction workers more secure |
| Edge Processing | Four long edges will be chamfered to convenient and safe holding |
| Usages | 1)for all kinds of fumigation-free packaging ; formwork ;Construction beams, rafters and columns for wide range of buiding structurals . 2)wood-based alternative to structural steel or reinforced concrete. 3) Packaging Material for mechanical equipment |
| Advange | LVL strength is three times of the same size solid wood, which is more suitable for load-bearing use |
| Packing | Pallets on the bottom,and Steel band for strength |
| Test: Static bending strength ≥50MPa Modulus of elasticity ≥7,000MPa | |
| Length | 3900-6000 mm |
| Wide | 225-1500 mm |
| Thickness | 38- 42m |
What’s LVL Scaffolding Plank?
Lightweight and durable (it is the lightest weight laminated wood scaffolding plank at the market), the scaffolding
plank is dimensionally stable and cost effective. Enhanced deflection values allow far greater degrees of safety and inherent defects with solid wood boards are eliminated. No more end banding is required, reducing repair and maintenance issues.
Properties of LVL Scaffolding plank
1.Enhanced durability and safety (OSHA)
2.Unrivalled structural rigidity, stability and strength
3.Proven to at least twice as long as solid wood equivalents
4.10% lighter than solid wood equivalents
5.No metal end band required
6.No on-going maintenance or remedial repairs required
7.Excellent electrical insulation properties
8.Excellent anti-corrosive and chemical properties
